Yachts for sale / Ocean King DOGE 500

2028 Ocean King DOGE 500

Fort Lauderdale, FL, US 163.5 ft · 29.5 ft' beam 6 cabins 16 kn kn top
Asking
Price on request
Our Thoughts

The 2028 Ocean King Doge 500 represents a significant achievement in modern explorer yacht design—a 163.5-foot full-displacement steel motor yacht engineered for serious transoceanic cruising without compromise on comfort or contemporary luxury. Built by Ocean King in Chioggia, Italy, and styled by the acclaimed Design aLOT studio, this vessel sits at the top of the successful Doge series and embodies the builder's three-decade heritage in commercial steel construction applied to high-end yacht ownership.

Hull, Propulsion & Performance

The Doge 500's steel hull with integral bow bulb and aluminum superstructure is engineered to RINA C + HULL • MACH; Y classification for unrestricted navigation, providing the structural integrity required for extended ocean passages. Twin MAN D2862 LE489 V12 diesel engines deliver 1,450 horsepower each at 100 percent load, driving the vessel through direct shaft-line propulsion to a maximum speed of 16 knots and a comfortable cruising speed of 14 knots. At 10-knot transit, the yacht achieves a 4,500-nautical-mile range—a capability that opens genuine blue-water exploration to owners who value both distance and deliberate passage-making. The 17,171-gallon fuel capacity and 3,698-gallon fresh water tank support extended voyages, while dual 118 kW 50 Hz generators and one 65 kW 50 Hz generator provide robust electrical redundancy. An optional upgrade to twin CAT C32 Acer V12 engines offering 1,600 horsepower each is available for owners prioritizing higher cruise speeds.

Accommodations & Interior Layout

The interior philosophy balances sophisticated design with functional seafaring practicality. The Doge 500 sleeps 12 guests across six staterooms and carries a crew of nine in five dedicated cabins, with flexible accommodation arrangements that maximize the utility of the 499-gross-ton platform. The owner's deck features a private front-facing terrace and large pool, creating an exclusive retreat separate from guest areas. A crow's nest positioned at the yacht's highest point delivers unobstructed panoramic views—a signature feature that emphasizes the vessel's explorer DNA. The wide, open stern accommodates twin fold-out balconies with direct sea access, ideal for entertaining, water sports, or simply watching the ocean. The layout demonstrates thoughtful space utilization rarely achieved in a vessel of this length, with carefully selected materials, harmonious color palettes, and refined finishes throughout.

Technical & Design Character

The engine room follows commercial ship standards with increased ceiling heights and efficient layout, supporting the yacht's long-range capability while remaining accessible for maintenance. The robust construction in high-grade metal with top-tier finishes provides the durability and reliability expected from Ocean King's shipbuilding pedigree. Expansive glazing throughout the interior brings natural light and seascape views into every major space, reinforcing the connection between interior comfort and the ocean environment. The exterior design balances bold, refined lines with the signature vertical bow and open-deck spaces that define contemporary explorer aesthetics.

Customization & Ownership

The Doge 500 is offered as a customizable platform, allowing owners to tailor systems, finishes, and layouts to their specific vision—whether the yacht serves as a private retreat or an active world cruiser. The combination of full-displacement hull form, commercial-grade construction, transoceanic range, and thoughtful luxury accommodations positions the vessel for owners who understand

Provided listing description Click to read the original broker text

The Ocean King Doge 500 stands as the pinnacle of the esteemed Doge series, representing the perfect fusion of Italian design elegance and true explorer yacht capability. Crafted by the accalaimed Design aLOT studio, this 164-foot masterpiece boasts bold yet refined exterior lines, a signature vertical bow, and expansive glazing that brings natural light and sea views into every corner of the vessel. With a steel hull engineered for long-range transoceanic passages, the Doge 500 is built to explore without sacrificing luxury. From bow to stern, the Doge 500 is a study in balanced design- blending open decks with intimate lounges, communal living spaces with serene private retreats. The wide, open stern features twin fold-out balconies, offering direct access to the sea and an ideal space for entertaining or relaxing. On the upper levels, the dedicated owner's deck offers a private front-facing terrace and a generous pool, while the crow's nest delivers breathtaking panoramic views from the yacht's highest vantage point. The interior design reflects a philosophy of sophistication and function. Carefully selected materials, harmonious color palettes, and refined layout choices come together to create an ambiance that is both luxurious and inviting. Every detail has been considered to ensure comfort at sea, from the flexible accommodation arrangements to the smart use of space rarely seen in a 164 ft vessel. Technically advanced, the Doge 500 features a robust engine room inspired by commercial ship standards. With increased ceiling heights and an efficient layout, it supports the yacht's 4,500 nm range- ideal for adventurous owners looking to cross oceans in style. Constructed in high-grade metal with top-tier finished, the Doge 500 offers a fully customizable platform tailored to meet each client's vision. Whether used as a luxurious private retreat or a capable world cruiser, the Doge 500 promises unmatched capability and comfort on the water.

Ocean King Doge 500: A 164-Foot Explorer Yacht Built for Transoceanic Voyages
The Ocean King Doge 500 represents the flagship model of Ocean King's acclaimed Doge series, a 163.5-foot steel-hulled explorer yacht engineered for extended ocean passages while maintaining the refined comfort standards expected in contemporary luxury cruising. Built in 2028 by the Chioggia-based Ocean King shipyard and styled by the renowned Design aLOT studio, this full-displacement vessel combines Italian design sophistication with commercial-grade construction principles, positioning it as a capable world cruiser for owners seeking both seaworthiness and elegance.
Overview and Design Philosophy
Ocean King's three-decade heritage in commercial steel shipbuilding informs every aspect of the Doge 500's construction and layout. The vessel's full-displacement hull with integrated bow bulb, combined with a steel hull and aluminum superstructure, provides the structural integrity required for unrestricted ocean navigation under RINA C + HULL and MACH Y classification. At 163.5 feet in length with a 29.5-foot beam and 7.7-foot minimum draft, the Doge 500 achieves a displacement of 490 tons at full load, supporting a gross tonnage of 499. The exterior design language emphasizes the yacht's explorer credentials through bold yet refined lines, a signature vertical bow that cuts efficiently through heavy seas, and expansive glazing strategically positioned to maximize natural light and sea views throughout the vessel. This approach balances aesthetic refinement with functional oceangoing capability—a hallmark of contemporary explorer yacht design that prioritizes visibility and connection to the marine environment without compromising structural strength or weather protection.
Deck Layout and Outdoor Living Spaces
The Doge 500's deck plan reflects a thoughtful hierarchy of spaces designed for both intimate relaxation and social entertaining. The wide, open stern features a distinctive design element: twin fold-out balconies that extend the usable deck area and provide direct access to the water, creating an ideal platform for water sports, tender operations, or simply enjoying the ocean at anchor. The stern configuration also accommodates the option for a large pool with additional folding balconies, a feature that elevates the vessel's appeal for extended cruising and entertaining. The owner's deck occupies a dedicated level and includes a private front-facing terrace, offering a secluded outdoor retreat separate from guest and crew areas. This spatial separation reflects the careful zoning evident throughout the yacht's design, where private owner spaces, communal entertaining areas, and service corridors are strategically positioned to minimize interaction while maintaining efficient circulation. The crow's nest, positioned at the yacht's highest vantage point, delivers panoramic views and serves both aesthetic and practical purposes—offering unobstructed sightlines for navigation, wildlife observation, and the kind of elevated perspective that defines the explorer yacht experience. The inclusion of such a feature, combined with the owner's private terrace and stern balconies, demonstrates how the Doge 500 prioritizes multiple outdoor living scenarios across its 163.5-foot length.
Guest and Crew Accommodations
The Doge 500 accommodates 12 guests distributed across 6 staterooms, with an additional 5 crew cabins supporting a complement of up to 9 crew members. This accommodation ratio reflects the vessel's positioning as a capable cruising platform suitable for extended voyages where professional crew expertise and availability are essential for safe ocean passages and day-to-day operations. The flexible accommodation arrangements noted in the broker description suggest that the stateroom configurations can be tailored to individual owner preferences—a significant advantage in a custom-build platform where the interior layout can be modified to prioritize, for example, larger master accommodations, additional guest suites, or dedicated spa and wellness facilities. This customization approach is particularly valuable for owners planning extended cruises where guest comfort directly influences the success of extended voyages.
Interior Design and Living Spaces
The interior design philosophy emphasizes sophistication and functional efficiency through carefully selected materials, harmonious color palettes, and refined spatial planning. The Doge 500 demonstrates sophisticated use of space rarely achieved in vessels of this size—a testament to both Design aLOT's expertise and Ocean King's experience translating commercial shipbuilding principles into luxury applications. The layout balances open communal living spaces with intimate private retreats, accommodating both social entertaining and the solitude necessary for extended cruising. The yacht's generous glazing strategy, mentioned throughout the design brief, ensures that even interior spaces benefit from natural light and connection to the surrounding seascape—a design principle that significantly enhances the psychological comfort of long-duration voyages. The interior finishes reflect high-grade metal construction standards, with top-tier finishing materials that balance durability with aesthetic refinement. This construction approach, inherited from Ocean King's commercial shipbuilding heritage, prioritizes longevity and ease of maintenance—practical considerations that gain importance during extended offshore passages where repair facilities may be distant.
Engine Room and Propulsion Systems
The Doge 500's engine room exemplifies commercial ship design principles adapted for luxury yacht applications. Increased ceiling heights and an efficient layout support the vessel's extended range capability while facilitating crew access for routine maintenance and emergency repairs—critical considerations for world cruising where professional support may be unavailable. The standard propulsion configuration features twin MAN D2862 LE489 V12 diesel engines, each producing 1,450 horsepower at full output, delivering direct shaft line propulsion. This twin-engine arrangement provides redundancy essential for ocean passages, ensuring continued propulsion capability if a single engine requires service or repair. The MAN D2862 series represents a proven, widely-supported commercial marine engine platform with global service infrastructure—an important consideration for owners planning extended cruises to remote regions. An engine upgrade option is available, featuring twin CAT C32 Acer V12 engines rated at 1,600 horsepower each, offering increased power for improved transit speed or better performance in challenging sea conditions. The availability of multiple engine options reflects the Doge 500's position as a customizable platform where owners can tailor propulsion characteristics to their specific cruising priorities.
Range, Fuel, and Water Systems
The Doge 500's design supports a 4,500-nautical-mile range at 10-knot cruising speed—a capability that enables true transoceanic voyaging without frequent refueling stops. This extended range is supported by a fuel tank capacity of 17,171 gallons (65,000 liters), providing the fuel volume necessary for extended passages while maintaining reasonable weight distribution and stability characteristics. Fresh water capacity of 3,698 gallons (14,000 liters) supports extended cruising with a crew complement of up to 9 and guest accommodations for 12, with black and grey water tank capacity matching fresh water capacity at 3,698 gallons. These tank sizes reflect the vessel's design as a capable offshore cruiser where self-sufficiency and extended periods away from shore-based infrastructure are fundamental operational requirements.
Power Generation and Ship Systems
The Doge 500 features three diesel generators: two 118-kilowatt units rated for 50-hertz operation and one 65-kilowatt unit, providing redundant power generation capacity and flexibility for varying electrical demands during cruising and at-anchor operations. This multi-generator approach ensures continuous electrical supply for climate control, refrigeration, navigation electronics, and all hotel loads even if a single generator requires service.
Performance and Cruising Characteristics
The Doge 500 achieves a maximum speed of 16 knots and maintains an economical cruising speed of 14 knots, performance characteristics consistent with a full-displacement hull optimized for efficiency rather than speed. This speed profile reflects the explorer yacht philosophy where range and seaworthiness take precedence over maximum velocity—a design priority that directly supports extended ocean passages where fuel efficiency and comfort at cruising speed matter more than peak speed capability. The 14-knot cruising speed provides reasonable transit times across ocean basins while maintaining the fuel efficiency that enables the vessel's 4,500-nautical-mile range. At this speed, the Doge 500 can comfortably transit between continents with minimal refueling stops, a practical advantage for owners planning extended world cruises.
Classification and Regulatory Compliance
The Doge 500 holds RINA C + HULL and MACH Y classification with unrestricted navigation approval, certifications that validate the vessel's design and construction for unlimited ocean voyaging. RINA (Registro Italiano Navale) classification represents European maritime authority validation of hull strength, structural integrity, and seaworthiness standards. The unrestricted navigation notation confirms that the vessel meets all international maritime regulations for unlimited ocean passages without geographic or seasonal restrictions.
Builder Heritage and Construction Standards
Ocean King's location in Chioggia, within the Venice lagoon, positions the shipyard within a region with nine centuries of continuous shipbuilding tradition. This heritage informs the
Length
163.5 ft
Beam
29.5 ft'
Year
2028
Builder
Ocean King
Model
DOGE 500
Cabins
6
Max speed
16 kn kn
